Principales caractéristiques et performances
-
Écran haute luminosité intégré : Comprend un 7-inch 1080p touchscreen with a brightness of 1000 nits, making it fully readable even in direct sunlight.
-
Portée étendue : Equipped with a 2T4R antenna system, it supports a transmission range of up to 15 km (FCC) or 8 km (CE/SRRC), ensuring stable 4K/60fps video downlink.
-
Durabilité industrielle : Rated at IP54 for dust and water resistance, the controller is designed to operate in extreme temperatures ranging from -20°C to +55°C.
-
Android-Based Ecosystem: Runs on an Android system with the GDU Flight II app pre-installed, supporting third-party development and customizable button mapping (L1/L2/R1/R2 and C1/C2).
-
Dual Battery System: Includes a 7000mAh built-in battery plus support for an optional external battery, extending total operating time to approximately 3 heures.
Spécifications techniques
| Fonctionnalité | Détails |
| Screen | 7″ Touchscreen (1920 x 1080), 10-point multi-touch |
| Transmission Frequency | Dual-band 2.4 GHz & 5.8 GHz |
| Sortie vidéo | HDMI (supports 4K/60fps H.265 transmission) |
| Stockage | 4GB RAM + 64GB ROM (expandable via SD card to 128GB) |
| Connectivité | USB-A, USB-C (charging/data), HDMI, SIM card slot |
| Satellite Positioning | GPS + BeiDou |
| Chargement | Fast charging: 0–90% in 1.5 hours |
User Experience & Control
The controller is designed for ergonomic, high-stakes flight. It includes a dedicated Arrêt d'urgence button for instant hovering, a physical Flight Mode Switch (Tripod, Standard, Sport, and Attitude modes), and dual dials for simultaneous gimbal pitch and EV adjustment.
Note: The device supports “short message communication,” allowing it to send data and messages even in areas without traditional 4G/5G cellular coverage when paired with the S200 drone’s satellite capabilities.
