Características principais
-
Ultra-Wide Vertical Vision: Com um $105.2^\circ$ vertical field of view, it can simultaneously see the ground immediately surrounding a vehicle and overhead obstacles, providing comprehensive coverage that standard LiDARs miss.
-
High-Resolution Mapping: Despite being a short-range sensor, its 128 channels generate up to 1.15 million points per second, creating a dense, high-definition 3D point cloud.
-
Blind Spot Master: It is optimized to detect small objects, pedestrians, and pets at extremely close range (as close as 0.05 m).
-
Automotive-Grade Reliability: Built to withstand harsh environments with IP6K7 e IP6K9K ratings, and an operating temperature range of -40ºC para 85ºC.
Especificações técnicas
| Parâmetro | Especificações |
| Canais | 128 |
| Campo de visão horizontal | 360º |
| Campo de visão vertical | 105.2º (-52.6º para +52.6º) |
| Alcance máximo | 50 m (20 m @ 10% reflectivity) |
| Min Range | 0.05 m |
| Angular Resolution | 0.4º (Horizontal & Vertical) |
| Precisão de alcance | +- 3 cm (typical) |
| Consumo de energia | 12 W |
| Peso | 700 g |
Recommended Applications
-
Robotaxis & Robotrucks: Used as a secondary sensor to cover the “dead zones” around the vehicle body.
-
Last-Mile Delivery: Navigating complex sidewalk environments and avoiding low-lying obstacles.
-
Warehousing & Logistics: Precision maneuvering for AGVs (Automated Guided Vehicles) in tight aisles.
-
Infraestrutura Inteligente: Monitoring pedestrian flow and intersection safety.
