Use only with certified tether kits or DJI-approved docks.
Do not splice or modify the tether cable.
Check connectors for debris before each flight.
Especificações
Capacity: 20 254 mAh
Standard Voltage: 48.23 V
Max Charging Voltage: 54.6 V
Battery Type: Li-ion 13S
Energy: 977 Wh
Net Weight: Approx. 4.72 kg (10.4 lb)
Operating Temp: –4 °F to 122 °F (–20 °C to 50 °C)
Charging Temp: 41 °F to 113 °F (5 °C to 45 °C) — self-heats below 5 °C
Discharging Temp: –4 °F to 122 °F (–20 °C to 75 °C)
Self-Heating: Supported (single, onboard, station)
Max Discharge: 4 C discharge
Charge: 2 C charge
Cycle Life: ˜ 400 cycles
Charging Time: 45 min (220 V, Fast) | 70 min (110 V, Fast) | 110 min (Silent)
Tethered Support: Compatible with approved third-party power-over-cable systems; includes reserved ports for dock integration
Compatibilidade
DJI Matrice 400 Series
BS100 Battery Station
Approved third-party tether kits & drone docks
