Características y capacidades clave
-
Reinforcement Learning (RL) Gait Control: Unlike robots with hard-coded movements, the D1 Ultra uses advanced RL algorithms to adapt its movement in real-time. This allows it to maintain balance on loose rubble, slippery surfaces, and uneven terrain.
-
High-Power Drive System: Built with an industry-leading drive system offering a specific power of 2kW/kg, it provides the high torque necessary for rapid acceleration and recovery from falls.
-
All-Terrain Agility: The robot is capable of climbing stairs taller than 16 centímetros, tackling slopes up to 30° (with an extreme limit of 40°), and performing athletic maneuvers like jumps (up to 35 cm) and flips.
-
Expansión modular: It features a standardized interface for secondary development, allowing users to mount LiDAR, RGB-D cameras, 4G/5G modules, o robotic arms.
Especificaciones técnicas
| Característica | Especificación |
| Máxima velocidad | 3.7 m/s (Limit up to 5 m/s) |
| Capacidad de carga útil | 8 kg (Static load up to 10 kg) |
| Dimensiones (de pie) | 630 x 360 x 415 mm |
| Peso | 15 kg (including battery) |
| Duración de la batería | 1–2 hours (supports hot-swappable batteries) |
| Clasificación de protección | IP54 (Dust and splash resistant) |
| Joint Peak Torque | ~48 N·m |
| Temperatura de funcionamiento | 0°C a 40°C |
Target Applications
The “Ultra” designation makes this model suitable for scenarios that require more reliability than a standard hobbyist robot:
-
Inspección Industrial: Navigating power plants, factories, or oil and gas sites to monitor gauges and detect leaks.
-
Seguridad y patrullaje: Autonomous surveillance in large warehouses or outdoor perimeters.
-
Emergency Response: Exploring hazardous areas or disaster zones where human entry is unsafe.
-
Advanced Research: Used as a hardware platform for universities developing new AI-driven motion or navigation software.
