High Capacity and Power Output:
- Boasting a 1024 Wh battery capacity, it delivers a whopping 2200-2400W of maximum AC output, making it suitable for even demanding devices.
Fast Charging:
- Unleash your aerial creativity faster. The DJI Power 1000 rapidly charges compatible DJI drone batteries, with some models reaching full charge in around 30 minutes.
Versatile Power Delivery:
- Keep all your gear juiced up. It features dual USB-C ports with Power Delivery 3.1 supporting up to 140W each, ideal for laptops, cameras, and smartphones.
Eco-Friendly Recharging:
- Embrace sustainable power. The DJI Power 1000 can be charged using solar panels (sold separately) through the DJI Power Solar Panel Adapter Module (MPPT) for off-grid adventures.
Durable and Safe:
- Built to last. It utilizes an LFP cell boasting a 10-year lifespan, retaining over 70% capacity after a staggering 4000 charge cycles. Additionally, various safety features ensure worry-free operation.
Quiet Operation:
- Enjoy peaceful power. The DJI Power 1000 operates at a low noise level, making it ideal for filming or use in noise-sensitive environments.
Extensive Accessory Options (sold separately):
- Expand its functionality with a variety of accessories, including the aforementioned solar panel adapter and car charger, for even greater versatility.
In summary, the DJI Power 1000 is a powerful and portable solution for content creators, drone enthusiasts, and anyone needing reliable off-grid power for their devices.
Technical Specifications
General
-
Model
-
DYM1000L/DYM1000H
-
-
Capacity
-
1024 Wh
-
-
Net Weight
-
Approx. 13 kg
-
-
Dimensions
-
448×225×230 mm (L×W×H)
-
-
Number of Ports
-
AC Output × 2
USB-C × 2
USB-A × 2
SDC × 1
SDC Lite × 1
AC Input × 1
-
-
Max Operating Altitude
-
3000 m
-
Output Specifications
-
AC Output
-
DYM1000L: AC 100-120 V, 50/60 Hz, max continuous output: 2200 W
DYM1000H: AC 220-240 V, 50/60 Hz, max continuous output: 2400 W Max continuous output power is available when the product’s battery level is above 20%. AC output data varies by country and region.
Given that the voltage in Japan is 100 V, the max continuous output power of the Japanese version is 2000 W.
-
-
AC Output (Bypass Mode)
-
DYM1000L: AC 100-120 V, 12 A, 1440 W
DYM1000H: AC 220-240 V, 10 A, 2200 W
-
-
USB-A Output
-
5 V, 3 A
9 V, 2 A
12 V, 2 A
Max output power per channel: 24 W
-
-
USB–C Output
-
5 V, 5 A
9 V, 5 A
12 V, 5 A
15 V, 5 A
20 V, 5 A
28 V, 5 A (EPR)
Max output power per channel: 140 W** The USB-C port supports a max output power of 140 W. The device being charged must support the PD 3.1 protocol and use a USB cable that meets EPR specifications.
-
-
SDC and SDC Lite Output
-
SDC: 9-27 V, max current: 10 A, max output power: 240 W
SDC Lite: 9-27 V, max current: 10 A, max output power: 240 WBoth of the SDC and SDC Lite ports support extensive accessories.
-
Input Specifications
-
AC Input
-
DYM1000L: AC 100-120 V, 1200 W (recharging), 1440 W (Bypass mode)
DYM1000H: AC 220-240 V, 1200 W (recharging), 2200 W (Bypass mode)
-
-
SDC and SDC Lite Input
-
SDC: DC 32-58.4 V, max 400 W, 8 A
SDC Lite: DC 32-58.4 V, max 400 W, 8 ABoth of the SDC and SDC Lite ports support extensive accessories.
-
Battery
-
Cell Chemistry
-
LFP (lithium ferrophosphate)
-
-
Cycle Life
-
Maintains over 70% capacity after 4000 cycles.
Measured at 25℃/77°F room temperature, being recharged in the 600W Standard Recharge Mode, and at an output power of 1000 W.
-
Operating Temperature
-
Power Supply Temperature
-
-10° to 45° C (14° to 113° F)
-
-
Recharging Temperature
-
0° to 45° C (32° to 113° F)
-
-
Storage Temperature
-
-10° to 45° C (14° to 113° F)
-
